Yamaha Personal Powered 45watt Full Range Monitor

$170.00

Model# MS202

Designed as a personal monitor this small Powered Speaker Cabinet has a Big Sound, it comes from the two 4" full range speakers and since magnetic field-canceling speakers are used, it can be placed next to a PC screen without interfering with the picture, making it the perfect choice for keyboard players system application.

Used for a personal monitor in the keyboard area of my last band because the floor monitor was so hard to get into the keyboard area, it got its feed from the keyboard mixer monitor out and was placed up ear height. Since magnetic field-canceling speakers are used, it can be placed next to a PC screen or keyboard display screens without interfering with the picture, making it the perfect choice for the keyboard players area.

Description
A personal powered monitor speaker in near mint condition. Works perfect it's been taken care of. The drivers are in perfect condition and sound killer with just a few tiny marks on it. Everything works just like new and sounds perfect. Ideal for home recording, this powered monitor features clean 45W built-in power amplifier; wide frequency response (70Hz-18kHz); 1/4" inputs and line out; magnetic shielding for use near CRTs; and comprehensive low, high, EQ, and volume controls. Includes 2 - 4" full range audio cone speakers.

Controls:
· Mic
· Master
· Tone:
· Lo-max +12 dB at 100 Hz
· Center Flat
· Hi-max +12 dB at 10 kHz
· Power “ON/OFF”

Power Requirement:
· A0230 V, 50/60 Hz
· Power Consumption: 45 W

Specifications:
General
Type: Bass Reflex Powered Speaker
Frequency Range: 70 Hz - 18 kHz (Tone Con.:Flat)
Max SPL: 103 dB SPL (20W, 1m on axis)
Dimensions(W x H x D): 292 x 214 x198 mm (11-1/2 x 8-3/8 x 7-3/4 in)
Weight: 3.9 kg (8lb 6oz)

Speaker Section
Components: JA1060 (10cm (4in), Cone) x 2
Sensitivity: 90 dB SPL(1W, 1m on axis)
Nominal Impedance: 4 Ω

Amp. Section
Output Power: 45 W at 1 kHz, THD=0.5%, RL=4Ω
Frequency Response: 40 Hz - 20 kHz ±1/3dB
Input Sensitivity: MIC —50 dB / 10 kΩ / Phone Jack
Impedance: LINE 1, 2 —20 dB / 15 kΩ/ Phone Jack
Connectors:LINE 3 -20 dB / 15 kQ/ RCA Pin Jack
Output Level / Impedance: LINE OUT —20 dB / 600 Ω (Nominal) / Phone Jack
Hum & Noise: ≤ —58 dB (MASTER Volume : min)
