Mackie 4 Channel Ultra Compact Mixer with Phantom Power

$120.00 Reduced Price! $75.00

4 channel mixer
Model# 402VLZ4

Four Channel Ultra Compact Mixer ~ I used it to control the volume on the Marshall 1000w Amplifier, Very Clear Mixer

Description:
Now featuring Mackie's flagship Onyx mic preamps, the comprehensive Mackie 1402VLZ delivers the proven feature set, high-headroom/low-noise design and "Built-Like-A-Tank" construction that created an industry more than 25 years ago. From every input to every output, VLZ4 is optimized to deliver professional-quality results each and every time.
Power supply and operating manual included.

Reduced Price:
This Mixers channel one is dead, if you plug into channel two and leave the pan button out it plays in both channels. So you can plug into channel two and the microphone will be in both channels use input three and four for your instrument. I used this mixer by plugging my guitar processors dry out of the effects unit into channel two in mono (button out) and the stereo out of the effects unit plugged into both the Three & Four inputs to give me a cool mix of dry and effects, also my marshal amp has no volume or tone control so I was able to do that here. Be advised that this is actually a three channel mixer

That is why I had no need for channel one.

VLZ:
Each generation of VLZ mixers benefits from a reinvestment in performance, all without raising prices. By continuing to ignore the "race to the bottom," VLZ4 benefits from generations of performance improvements like transparent EQ, class-leading negative summing bus architecture and custom-designed op-amps to ensure signal integrity from every input to every output. The result is a mixer that is at the peak of performance and is the obvious go-to compact analog mixer for engineers who demand professional results.

Onyx:
The performance of Mackie's Onyx mic preamps is more than proven. Just check all the amazing reviews and customer testimonials. Their boutique quality sound and unmatched performance rival any high-priced, boutique preamp on the market. Adding these flagship preamps to our VLZ4 Series compact mixers underlines our commitment to continually improving the performance of the VLZ line with each generation.

Shhh...
The VLZ4 design goal was simple: every VLZ4 mixer must have the highest headroom and lowest noise possible. Strict attention to component quality and tolerances has led to innovations like our custom M80 op-amps and class-leading negative summing bus architecture that add yet another level of assurance that a Mackie VLZ4 mixer is the right choice for your professional audio application.

Reliable:
Mackie VLZ mixers are truly "Built-Like-A-Tank." From beer spills to drops from moving vehicles, the testimonials are as endless as the applications Mackie mixers serve. The VLZ4 series is certainly no exception. With a nearly indestructible steel wrap-around chassis and features like grime-resistant rotary sealed pots, you can be sure that buying a Mackie VLZ4 mixer is a solid investment.

VLZ4's new black powder coat finish, cockpit-inspired controls and high-contrast knobs not only optimize your mixer's usability in low-light scenarios, it also means your mixer looks as good as it performs.

Features:
· Boutique-quality Onyx mic preamps
· High-headroom, low-noise
· Rugged steel chassis
· Phantom power for condenser mics
· High-resolution 8-segment stereo meters
· Sealed rotary controls resist dust and grime
Specifications:
Main Mix Noise
· (20 Hz-20 kHz bandwidth, channels 1-3 gain @ unity, channel EQs flat, all channels assigned to main mix, channel 1 panned left,
   2 panned right, 3-8 centered.)
· Main mix knob down, channel level knobs down: XLR: -95 dBu TRS: -101 dBu
· Main mix knob @ unity, channel level knobs down: XLR -90 dBu, TRS -96 dBu
· Main mix knob @ unity, channel level knobs @ unity: XLR dBu-84, TRS dBu -90

THD
· (1 kHz @ 30 dB gain, 20 Hz-20 kHz bandwidth) Mic pre @ insert: <0.001%

EQ
· High Shelving
· Low Shelving

Attenuation/Crosstalk
· (1 kHz relative to 0 dBu, 20 Hz-20 kHz bandwidth, line in, 1/4" main out, gain @ unity)
· Main mix knob down: -75 dBu
· Channel Alt / Mute switch engaged: -100 dBu
· Channel level knob down: -100 dBu
· Frequency Response
· Mic input to main output (gain @ unity)
· +0, -1 dB, 20 Hz to 50 kHz +0, -3 dB, <10 Hz to >100 kHz
· Equivalent Input Noise (EIN)
· (Mic input to insert send out, max gain)
· 150 termination: -128.5 dBu, 20 Hz-20 kHz

Common Mode Rejection Ratio (CMRR)
· 1 kHz: better than -70 dB

Maximum Levels
· Mic in: +21 dBu
· Tape in: +24 dBu
· All other inputs: +22 dBu
· All outputs: +22 dBu

Impedances
· Mic in: 2.55
· Channel insert return: 5K
· All other inputs: 17K or greater
· Tape out: 1.0K
· Phones out: 60
· All other outputs: 120

Physical Properties
· Height: 7.3"
· Depth: 1.6"
· Width: 5.8"
· Weight (with power supply): 3.0lb
· Weight (without power supply): 2.5lb
Used – Mint

Same Day Shipping - Ships from Blonds personal stash
Located in: New Orleans, Louisiana, United States

Handling Cost:
$20.00 will be added on items over 30lb
$50.00 will be added on items over 100lb
Free local pickup

Shipping: Calculate

make an offer
