DOD Stereo Fifteen-Band Graphic Equalizer has XLR & ¼" In~Outs

$160.00

DOD Mixer
Model# SR430QX

Stereo 15-band EQ (2 channels with 15 bands per channel) with 2/3 octave controls for accurate control of sound.

This is a dual channel, 15 band 2/3 octave graphic equalizer which features constant Q circuitry, housed in a single space rack. The sliders are 20mm center detent, with 12 dB of boost and cut for each slider.

The unit provides active balanced input and output connections, high pass filters, bypass switches for each channel, and an internal power supply. Electronic switching of the bypass minimizes switching transients, such as loud pops or clicks when the switch is depressed. The unit has a fully shielded internal transformer provides extremely quiet operation, and multiple input and output configurations are provided for ease of use. The XLR and 1/4" TRS connectors use active balanced, low noise circuitry, while the 1/4" connectors will also accept an unbalanced plug.

The input level control covers a wide range, thus allowing the unit to work with a variety of signal levels. The Graphic Equalizer may be used in a variety of applications such as live sound, recording studios, instrument racks, as well as any conventional fixed installation environment.

Features:

 · Dual channel 15 band 2/3 octave graphic equalizer
· Constant-Q filtering
· 20mm center detent sliders
· Low cut filter at 50Hz with a 12dB/Octave Slope
· Variable input level control
· Balanced XLR inputs and outputs
· Balanced 1/4" inputs and impedance balanced 1/4" outputs
· /-12dB boost/cut per band and input control w/LED meters
· Balanced XLR and 1/4" inputs and outputs
· Low cut filter at 50Hz with a 12dB/Octave Slope


Specification:
Number of Channels	2
Inputs 2 x XLR, 2 x 1/4" TRS phone
Output 2 x XLR, 2 x 1/4" TRS phone
Used – Like New

Same Day Shipping - Ships from Blonds personal stash
Located in: New Orleans, Louisiana, United States

Handling Cost:
$20.00 will be added on items over 30lb
$50.00 will be added on items over 100lb
Free local pickup

Shipping: Calculate
